· Pumping rate (50HZ/60HZ): 25/30m'/h
· Ultimate pressure (excluding gas ballast valve): 0.1…0.5, see the brand name for parameters (NP) hPa (mbar) abs.
· Ultimate pressure (including gas ballast valve): 0.5…1.5hPa (mbar) abs
· Motor rated speed (50HZ/60HZ): 1500…1800min1
· Motor rated power (50HZ/60HZ): 1.0/2.0KW
· Energy consumption under 100MBAR (50HZ/60HZ): 0.8/0.9KW
· Extreme Energy consumption under limited pressure (50HZ/60HZ): 0.5/0.6KW
·Sound pressure level (ENISO2151 standard) (50HZ/60HZ): 60/63dB(A)
·Maximum saturated vapor pressure of water vapor (with gas ballast valve): 40hPa(mbar)
·Water vapor handling capacity (with gas ballast valve): 0.9KG/h
·Ambient temperature range: see the manual "Vacuum pump special oil" 27℃
·Ambient pressure: atmospheric pressure
·Vacuum pump special oil-dosage: 0.5L
·Appearance size: 650*280*750mm
·Gas tank capacity: 40L
