·Scanning method: non-contact line laser scanning and self-light texture scanning, no harm to human body and eyes
·Scanning range (X, Y, Z): 350x170x50 mm
·Scanning error: ±0.5 mm
·Scanning time: 5-10s
·Overall size (L x W x H): 585x290x120mm
·Application software: Basinlead
·Operating system: Windows7/10 64-bit
·The 3D scanning of the sole adopts 4+1 scanning angles, that is, the sole is scanned from 4 angles. In addition to scanning the bottom of the sole, it can also scan the front, back, left, and right sides of the sole. +1 is a rear-view camera, which can observe the inversion and inversion of the heel
·Equipped with a rear camera and a laser head, the rear camera shoots the inversion and inversion of the heel, and the rear laser head prompts the standing position of the human body
·The scanning object can scan both the sole and the mold box, and both can calculate parameters and issue measurement reports
·The output format of the scanned data supports general data formats such as STL and OBJ, and can be directly input into the correction insole design system without special processing
·The software operation process adopts a wizard-style operation, and there is a voice prompt for each step of the operation process
·Supports WeChat public account access, users scan the QR code to transmit the sole data to the mobile phone
